Steel is new

Markus F

Aktiv medlem
Steel is new
Jag har alltid rätt.

http://bikemag.com/news/newsarchive/110305_dain/
http://www.ifbikes.com/news.php?id=76
http://www.cyclingnews.com/tech/2005/shows/australia05/?id=results/australia051



Shick

Ny medlem
Steel is new
För alla som undrade: Jag såg ett växelöra idag som såg ut ungefär som det gör på den där ramen eller är det en dropout? :S


Kneecap

Aktiv medlem
Steel is new
Tjena!

Markus.. Om inte mitt minne är helt ur funktion så har detta redan avhandlats i en tråd om Interbike..
Eller så var det på något annat obskyrt forum om casting elle rnån annan sjuk sport men det tror jag inte.. :D


Markus F

Aktiv medlem
Steel is new
Kneecap skrev:
-------------------------------------------------------
> Tjena!
>
> Markus.. Om inte mitt minne är helt ur funktion så
Jo, det avhandlades som hastigast tidigare. Nu har det ju kommit mer info.


Kneecap

Aktiv medlem
Steel is new
Pelle Hå skrev:
-------------------------------------------------------
> Vad gör the_TnT i en radiostudio?
>
Tjena!

Mina grannar kan ju inte tro att jag är frisk som garvar så här högt mitt i natten..

Iofs så är det väl ganska sant också.. :P

Btw så tycker jag inte alls om Markus för att han påminde mig om dessa nya rör och de vackra ramar som skapsa utav dom.. Inte bra för mitt visakort..


Pelle Hå

Aktiv medlem
Steel is new
Kneecap skrev:
-------------------------------------------------------
> Mina grannar kan ju inte tro att jag är frisk som
> garvar så här högt mitt i natten..
>

Hehe, ja det var faktiskt lite likt på den bilden. :-D

> Btw så tycker jag inte alls om Markus för att han
> påminde mig om dessa nya rör och de vackra ramar
> som skapsa utav dom.. Inte bra för mitt visakort..
>

Jag väntar på en Ibis i trailutförande med slopat topprör och 2,7" däcksclearance. Det blir nog dyrt, men jag lär väl iofs ha tid på mig att spara. =)


Johan S

Ny medlem
Steel is new
En Reynolds 953-ram under 1000 gram(!). Säger som i artikeln: Jaw-dropping! Men så tunna rör som 0.3 mm måste väl vara känsligt för stötar?

edit: mät upp 0.3 mm med ett skjutmått: Jaw-dropping var bara förnamnet...

Senast redigerad av en moderator:

Orv

Ny medlem
Steel is new
this information is provided by Reynolds TI:
FAQs: Updated: 8 October 2005.
Reynolds Stainless 953

Thank you for enquiring about Reynolds 953 butted tube sets.
Because it is a new metal for use in the bike industry, we are working to ensure 953 allows for frame-builder processes but will expect there will be detailed questions that may require an periodic update. A separate file can be sent to you, indicating possible methods of frame-building with 953.

To cover questions that have been raised so far
• Material – maraging stainless steel, specially manufactured for Reynolds by Carpenter SpecialtyAlloys, USA. This material undergoes a double vacuum remelt process to get achieve the necessary properties and purity. It has a very low carbon content, which has an advantage that machinability compared to e.g. AerMet 100 which is improved due to low carbide content.
• Made from welded, cold-drawn tube with a highly homogenous welds to avoid a potential weak point (specialist aerospace weld mill). Although a departure from Reynolds' preference of using seamless materials for high-end tubing, the cost factor would make seamless material very expensive for a steel frame although this remains a future option. 953 passes 3 tests after ageing at 950F a) 50% flatten from e.g. 28.6mm OD to 14mm width without any cracking along the weld seam b) drilling into the weld seam area does not cause any seam cracking c) no visible seam line on the finished tube after polishing.
• Ultimate tensile strength – 1750 to 2050MPa depending on process used (853 air-hardening steel are 1200-1400 MPa). Density is 7.79 gm/cc. Poissons ratio is 0.30.
• Yield strength 1500-1900 MPa depending on the combination of cold-working, butting, and ageing temperature. (1500 MPa is approx. twice the yield strength of Cold-worked, Stress relieved 3-2.5 titanium). At 950 F ageing temperature, yield strength should be in the 1650-1730 MPa range based on internal tests. Elongation can be increased by changing the ageing temperature.
• Stiffness Modulus (E) is 200 GPa, similar to other steel alloys. Although Reynolds do not have frame design expertise, we assume that if higher stiffness is required when lighter tubes are used, advantage can be taken of the higher strength by using slightly oversize but thin wall tubes with a lower overall weight.
• Can be TIG welded or silver brazed using recommended filler wire. NB Silver brazing trials indicate this is workable, but an outstanding question is corrosion resistance on the braze area. There may be brazing materials with similar melting points but with the corrosion resistance of a stainless steel.
• High tensile / impact strength and fracture toughness. Workability before ageing.
• Corrosion resistance superior to type 410 stainless steels. Note that under some conditions e.g. sulphuric acid, prolonged submersion in sea water 953 will show signs of pitting and corrosion. We assume these are not normal conditions for a bike frame.
• Cold worked butted wall profiles from 0.65mm down to 0.3mm (e.g. .65/0.4/0.65, 0.5/0.30/0.50mm) depending on diameter
• Full range of stainless steel fittings / BB shell / head tube will be available in compatible alloys including 953 BB shell, 953 lightweight rear drop-outs.
• Tube diameters 28.6, 31.75, 34.9 & 36.4 mm.

• Variety of butt profiles to suit frame sizing and lugged construction if needed.

• Supplies of tube and fittings will be available to frame builders world wide early February 2006

• Full specification and pricing will be available end October 2005 after we finalize the initial tube specs and special fittings list. Reynolds will start taking orders from frame builders for 2006 delivery from end October.

• Tubes can be supplied ready aged, so frame builders can just fabricate the frames, but assume miter and cutting could be slow. Or we can supply without age, so frame building will be similar to standard CrMo steels, for the builder to age the whole frame. Full heat treatment details will be provided. Ageing will leave a superficial tint, which can be removed by light polishing, shot blasting or pickling. Frame alignment should be carried out before ageing but do not expect jigs to be needed when ageing as this is a relatively low temperature for steel heat-treatment.

Contact end October for specification and prices :-

For world wide sales, except North America,
Reynolds Cycle Technology (2000) Ltd
Tel +44 (0) 121 706 5151 Fax +44 (0) 121 707 0081, e.mail terryb@reynolds-cycle.com




Orv

Ny medlem
Steel is new
Hittade detta på http://www.bikeforums.net/archive/index.php/t-143207.html och lägger in det därför jag tycker det är bra:

DannoXYZ:
Based on those numbers it would seem Stainless is a very suitable material, It's strong and it has a nice elasticity. The 321 is inbetween the Titaniums in strength, yet less brittle.
Yeah, I think materials-selection is the easy part. It really comes down to implementation issues of structural design, manufacturing processes and cost. A SS-321 tubeset would be about 5x more expensive than chromoly and the proprietary Gall-Tough+ stuff ends up costing 10x more expensive than chromoly. In a custom-frame like a Serotta, Eisentraut or Steelman, there's so much labor and design costs built into the frame, that an extra $400-700 isn't really gonna make much of a difference. But when you're looking at mass-produced chromoly frames in the $300-400 range, then adding that extra expense for the exotic tubing may not be worth it. You'll get a better sense of "value" by going to titanium or alloy.

Since people brought up aluminium foil, here's the properties for aluminium:

Aluminum 6061-T6
density: 0.0975 lb/in^3
ultimate-strength: 42.0 kpsi
yield-strength: 37.0 kpsi
elongation@break: 12%
modulus elasticity: 10 kpsi

Aluminum 7005-T6
density: 0.100 lb/in^3
ultimate-strength: 50.8 kpsi
yield-strength: 42.1 kpsi
elongation@break: 13%
modulus elasticity: 10 kpsi

Aluminum 7075-T6
density: 0.102 lb/in^3
ultimate-strength: 83.0 kpsi
yield-strength: 73.0 kpsi
elongation@break: 11%
modulus elasticity: 10 kpsi

The comparison metric you'd want to use here is yield strength-to-weight ratios (density) as this would let you design frames that would hold up to roughly the same amount of load before they take a permanent bend. So now we're looking at (yield-strength / density):

Yield Strength-to-Weight Ratios
184 - chromoly 4130
448 - titanium 3Al-2.5V
679 - titanium 6Al-4V
208 - stainless 321
701 - stainless Gall-Tough+
379 - aluminum 6061-T6
421 - aluminum 7005-T6
716 - aluminum 7075-T6

However, you can't design something to be as light as possible for the load, there's rigidity and stiffness to be considered as well. So let's compare the stiffness-to-weight ratio (modulus / density):

Stiffness-to-Weight Ratios
105 - chromoly 4130
89.5 - titanium 3Al-2.5V
92.6 - titanium 6Al-4V
98.6 - stainless 321
97.5 - stainless Gall-Tough+
103 - aluminum 6061-T6
100 - aluminum 7005-T6
98.0 - aluminum 7075-T6

Interesting to see that the materials are similar in stiffness-to-weight, eh? That means a frame designed from these materials to be similar in weight, assuming similar designs, will have similar stiffnesses as well. However, titanium or aluminium will end up being 2-3.5x stronger for the same stiffness as chromoly. And ordinary 304 stainless is actually weaker than chromoly for the same stiffness, 321 is similar and the exotic stuff ends up about the same as high-end titanium & alloy materials at 3.5x stronger for the same stiffness as chromoly.

As a designer, you've got to strike a balance of these two factors in addition to the design, manufacturing and costs as well.


Kid1000

Aktiv medlem
Steel is new
Blanda in olika storheter i jämförelser är bara förvirrande.

Ingen lista på det nya übermaterialet i samma enheter som aluminiuminformationen?

Är meningen att man skall sitta o räkna?
