Säljes: Rivendell Custom

Borttagen

2002

Frame/Ram:
Design by Grant Petersen, Rivendell Bicyle Works.
Built by Curt Goodrich. Year built: 2002. Paint by Joe Bell, Ca, US
Frame Color: Dupont Imron, Turquosie. Window Fill: Dupont Imron, Cream #4296.
Seat tube: 570 mm c-t. Top tube parallel to the ground: 570 mm c-c. Top tube slope: 1.5°.
Chainstay length: 430 mm. BB drop: 80 mm. Fork rake: 45 mm.
Seat angle: 72 degrees. Head angle: 73 degrees.
Seat Post: Ø 27.2 mm. Rear Dropouts: 130 mm, horisontal.
Seat Tube: 28.6 mm
Pump Peg, 2 water bottle mounts.
Headset: Chris King 1" threaded "No Logo"

Tubing:
Top Tube: Reynolds 753, Ø 28.6, 0.8-0.6-0.8. Down Tube: Reynolds 725, Ø 31.8 mm, 0.8-0.5-0.8 mm.
Seat Tube: Reynolds 725, Ø 28.6, 0.8-0.6 mm.Head Tube: Reynolds 725, 0.9 mm.
Steerer: Reynolds 725. Seat Stay: Reynolds 725, Ø 16 mm x 0.8 mm.
Chain Stay: Reynolds road dented HT.
Fork Tubes: Reynolds 531, 0.9 mm tapering to 0.6 mm.
Lugs from Long Shen, Dropouts from Liow Ko.
Rear Rack mounts, front & rear mudguard eyelets.

s/n: 1016CG02

Finns en extra Tegnergaffel Kaisei Toei Imperial rör, 2012, för lowtrail, fäste för lowraider, frampakethållare.

Delar:
Grand Bois styrstam (Nitto), Compass/RH Maes Parallel styre (Nitto), Nitto "Frog" sadelstolpe 27.2 mm.
Grand Bois Decaluer (Nitto)
Shimano bromsar std reach, Shimano Ultegra bakväxel, Shimano CX 70 framvx, Shimano Ultegra växelreglage 3 delat, 10 delat,
Shimano Kassett 12 x 30, Shimano kedja.
Shimano Dura-Ace nav 36 ekrat, med Mavic Open pro fälgar, GB Cypres Däck 622 x 30 mm
SON Naben Dynamo nav, Edelux 28", med Mavic Open pro, 32 ekrat. SOn Edelux II upside down framlampa.
Splitbox, för uttag av kabel till laddare.
Specialties TA Zephyr vevparti, 46 x 36 x 28, SKS JIS BSA vevlager 121 mm.
Honjo skärmar.
Veloform byggda packväskhållare fram, bak styr väskhållare.

Lite lack skador, men inga bucklor, som jag har sett.

Extra klingor fram finns:
49 1st ny, 48 1st ny 341st ny
beg: 46 2x, 36 2x, 34, 28, 24
Extra Honjo skärmar,

Rivendell SS tröja, LS tröja i merinoull, Rivendell Reader tidningar.
Extra Rivendell dekalset.
Pris 24000 SEK

Ny pris idag:
snip "
Custom Framesets - $5000+
We've stopped taking orders until we can get delivery down under two years.

Designed just for you. Handmade and painted by America's best.
These are the ones that get "Rivendell" decals"
